Digital Multimeter Ture RMS Auto Range 6000 Counts Multimetro 1000V 10A AC Ohm Hz NCV Live Voltage Temperature Meter(GD108A Auto Range)

Multimeters & AnalyzersProfessional Digital Multimeter 6000 Counts Multimetro 1000V 10A AC Ohm Hz NCV Live Temperature Duty Voltage MeterMultimeter is an Professional Multimeter which can measure AC and voltage, AC and current, resistance, capacitance, continuity, diode, NCV,etc.; It is the best choice for professional electrician, engineer, electronic enthusiast or family useProduct Features1) GD108Adual Color ScreenGD108B/C is Large display2) Maximum display: Maxium 6000 Counts display3) GD108A isAuto range, GD108B/C:Manual Range4) Sampling Rate: About 3 times per second5) Over range display: the highest position shows "OL"6) Low voltage display: low battery indication<;80%8) Power Supply: 2x1.5V Batteries ( NOT include)9) It is a stable performance, high precision, high reliability clear readings, and overload protection.Technical Details Voltage:GD108A/B/C : 600mV/6V/60V/600V/1000V (±(0.5%+3)AC Voltage:GD108A: 600mV ±(1.0%+5) 6V/60V/600V/750V ±(1.0%+5)GD108B: 6V/60V/600V/750V ±(1.0%+5)GD108C: 6V/60V/600V/750V ±(0.8%+5) Current:GD108A: 600uA/6000uA/60mA/600mA ±(0.8%+3) 6A/10A ±(1.2%+3)GD108B/C: 10A ±(1.2%+3)AC Current:GD108A: 600uA/6000uA/60mA/600mA ±(1.0%+3) 10A ±(1.5%+3)GD108B/C: 60mA/600mA ±(1.0%+3) 10A ±(1.5%+3)TemperatureGD108A: 40°C~1000°C ±(1.0%+3) -40°F~1832°F ±(1.0%+3)GD108B: (°C/°F):-40°C~1000°C ±(1.0%+3) -40°F~1832°F±(1.0%+3)GD108C: NOTResistance:600/6k/60k/600k/6M/60M±(0.8%+3)Capacitance:10nF/100nF/1F/10F/100F/1mF/10mF ±(4.0%+3) 100mF:±(5.0%+5)Frequency:10Hz/100Hz/1kHz/10kHz/100kHz/1MHz/10MHz ±(1.0%+3)Auto/Manual range:GD108A: Auto Range/ GD108B / GD108C :Manual RangeDisplay:GD108A: Dual Color Screen GD108B/GD108C: DisplayBargraph:only for GD108ABattery test(1.5V/9V): Only for GD108B / GD108CDuty:1%~99% ±(1.0%+2)Counts:6000 CountsLive Test:Yes (sound and light alarm)NCV: Yes (sound and light alarm)Diode Test:YesContinuity: Yes (sound and light alarm)Max/Min Hold: YesData Hold: YesTrue RMS: YesBandwidth:1kHzLow Battery Indication: YesAuto Power Off: YesBacklight: Double ColorInput Jack : LED IndicateWork Light:Power:2xAA BatteriesProduce Weight / Size: Approx. 350g / 188 x 88 x 58mmSafety Rating:EN61010-1,-2-030 EN61010-2-033, EN61326-1 III 1000V,CATIV 600VPaking Contents:1PC Digital Multimeter1PC User manual1pc Test Pen
