Mini Load Cell Sensor,Button Type Scale Weigh Force Pressure Sensor,Test Tension and Compression,High Precision 0.2% Diameter Φ20 mm*12mm with 3m Cable (0-200KG)

Rated Output：1.5±10%mV/V Non-linearity：±0.5 %F·S Lag error：±0.5 %F·S Repeatability：±0.3 %F·S Creep：±0.3 %F·S Zero temperature coefficient：±0.1 %F·S/10℃ Sensitivity temperature coefficient：±0.1 %F·S/10℃ Input resistance：1000±30Ω Working temperature：-20℃~+70℃ Safe overload：150 %F·S Insulation resistance：≥2000M Ω Incentive voltage：5V～12V Protection class：IP66 Material：Stainless steel Cable：φ3×3M

• High precision measurement: The use of advanced resistance strain gauge technology, combined with precision signal conditioning circuit, to ensure that in the range of 5kg to 500kg, the measurement accuracy is stable at ±0.2%, providing accurate data support for various weighing applications.
• Pressure point diaphragm structure design: The unique diaphragm structure, through the precise pressure point design, so that the sensor under vertical load, can be evenly distributed stress, improve the measurement accuracy and stability. At the same time, this design also enhances the sensor's resistance to lateral force and impact resistance, ensuring long-term stable operation under complex conditions.
• Wide range coverage: provides a variety of range options from 5kg to 500kg to meet the needs of different application scenarios. Whether it is product packaging and material sorting in light industry, or cargo lifting and warehousing management in heavy industry, you can find the most suitable sensor model.
• High stability and durability: The selection of high-strength, corrosion-resistant alloy materials, after special processing, to ensure that the sensor can maintain long-term stable operation in harsh environments. At the same time, it has excellent anti-fatigue and anti-aging ability to extend the service life.
